A patented mechanical dinghy securing system built from marine-grade stainless steel. No hydraulics, no electrics, no failure points. Just precision engineering that works at 40 knots.
Order — €699 View Full Specs
Complete specifications for the TenderConnect Dinghy Transport System
| Parameter | Value | Notes |
|---|---|---|
| Maximum dinghy length | 320 cm | Measured inflated |
| Load capacity | 100 kg | Dinghy + outboard combined |
| Max outboard weight | 25 kg | Remains mounted during transport |
| System weight | 10 kg | Complete kit |
| Packed dimensions | 60 × 40 × 25 cm | — |
| Mounting bolts required | 4 | Transom mount, templates included |
| Receiver material | 1.4584 | EN 10283 marine stainless steel |
| Boom material | 6082-T6 | Hard-anodized aluminium |
| Wind rating | 40 kn | Sustained, tested at sea |
| Operators required | 1 | Single-handed operation |
| Warranty | 5 years | Full manufacturer warranty |
A direct engineering comparison
| Criteria | TenderConnect | Traditional Davits |
|---|---|---|
| System weight | ✓ 10 kg | ✗ 20–40 kg |
| Attachment time | ✓ < 1 min | ✗ 5–15 min |
| Single-person operation | ✓ Yes | ✗ Often requires two |
| Water accumulation | ✓ None (angled drain) | ✗ Collects rain & spray |
| Wind resistance | ✓ Low profile | ✗ High windage |
| Deck space impact | ✓ Removable, no clutter | ✗ Permanent fixture |
| Outboard stays mounted | ✓ Yes, up to 25 kg | Varies by model |
| Moving parts / electrics | ✓ None | Some require electric winch |
| Price range | ✓ €699 | ✗ €800–3,000+ |
Every component is selected for long-term marine duty
High-molybdenum duplex stainless steel with exceptional resistance to pitting and crevice corrosion in chloride environments. Standard in offshore marine applications.
Heat-treated aluminium alloy with hard-anodized surface for maximum corrosion resistance. Excellent strength-to-weight ratio for structural marine components.
All supplied fasteners are A4-80 grade (AISI 316) for reliable corrosion resistance in permanent saltwater exposure.
Purely mechanical locking and release. No hydraulics, no electrics, no batteries. Works reliably every time with zero maintenance.
Order directly from the manufacturer. Ships from Germany.
